Polyethylene Pipes for Drinking Water and Gas

Since 2017 we are producing polyethylene pipes for water and gas supply ranging from 20 mm to 630 mm in diameter and with pressure ranges from PN6 to PN25. PE pipes for water supply meet the standards EN 12201-2:2011, ISO 4427-1:2019 ensuring their safety and performance. PE pipes intended for gas supply adhere to the standards ISO 17484-1:2012 and EN 155-2:2021.

O/D	I/D	S(mm)
315	299.6	7.7
355	337.6	8.7
400	380.4	9.8
450	428	11
500	475.4	12.3
560	532.6	13.7
630	599.2	15.4

O/D	I/D	S(mm)
315	295.6	9.7
355	333.2	10.9
400	375.2	12.3
450	422.4	13.8
500	469.4	15.3
560	525.6	17.2
630	591.4	19.3

O/D	I/D	S(mm)
50	46	2
63	58	2.5
75	69.2	2.9
90	83	3.5
110	101.6	4.2
125	115.4	4.8
140	129.2	5.4
160	147.6	6.2
180	166.2	6.9
200	184.6	7.7
225	207.8	8.6
250	230.8	9.6
280	258.6	10.7
315	290.8	12.1
355	327.8	13.6
400	369.4	15.3
450	415.6	17.2
500	461.8	19.1
560	517.2	21.4
630	581.8	24.1

O/D	I/D	S(mm)
40	36	2
50	45.2	2.4
63	57	3
75	67.8	3.6
90	81.4	4.3
110	99.4	5.3
125	113	6
140	126.6	6.7
160	144.6	7.7
180	162.8	8.6
200	180.8	9.6
225	203.4	10.8
250	226.2	11.9
280	253.2	13.4
315	285	15
355	321.2	16.9
400	361.8	19.1
450	407	21.5
500	452.2	23.9
560	506.6	26.7
630	570	30

O/D	I/D	S(mm)
32	28.2	1.9
40	35.4	2.3
50	44.2	2.9
63	55.8	3.6
75	66.4	4.3
90	79.8	5.1
110	97.4	6.3
125	110.8	7.1
140	124	8
160	141.8	9.1
180	159.6	10.2
200	177.2	11.4
225	199.4	12.8
250	221.6	14.2
280	248.2	15.9
315	279.2	17.9
355	314.8	20.1
400	354.6	22.7
450	399	25.5
500	443.4	28.3

O/D	I/D	S(mm)
32	28	2
40	35.2	2.4
50	44	3
63	55.4	3.8
75	66	4.5
90	79.2	5.4
110	96.8	6.6
125	110.2	7.4
140	123.4	8.3
160	141	9.5
180	158.6	10.7
200	176.2	11.9
225	198.2	13.4
250	220.4	14.8
280	246.8	16.6
315	277.6	18.7
355	312.8	21.1
400	352.6	23.7
450	396.6	26.7
500	440.6	29.7
560	493.6	33.2
630	555.2	37.4

O/D	I/D	S(mm)
25	21	2
32	27.2	2.4
40	34	3
50	42.6	3.7
63	53.6	4.7
75	63.8	5.6
90	76.6	6.7
110	93.8	8.1
125	106.6	9.2
140	119.4	10.3
160	136.4	11.8
180	153.4	13.3
200	170.6	14.7
225	191.8	16.6
250	213.2	18.4
280	238.2	20.6
315	268.6	23.2
355	302.8	26.1
400	341.2	29.4
450	383.8	33.1
500	426.4	36.8
560	477.6	41.2
630	537.4	46.3

O/D	I/D	S(mm)
20	16	2
25	20.4	2.3
32	26	3
40	32.6	3.7
50	40.8	4.6
63	51.4	5.8
75	61.4	6.8
90	73.6	8.2
110	90	10
125	102.2	11.4
140	114.6	12.7
160	130.8	14.6
180	147.2	16.4
200	163.6	18.2
225	184	20.5
250	204.6	22.7
280	229.2	25.4
315	257.8	28.6
355	290.6	32.2
400	327.4	36.6
450	368.2	40.9
500	409.2	45.4
560	458.4	50.8
630	515.6	57.2

O/D	I/D	S(mm)
20	15.4	2.3
25	19	3
32	24.8	3.6
40	31	4.5
50	38.8	5.6
63	48.8	7.1
75	58.2	8.4
90	69.8	10.1
110	85.4	12.3
125	97	14
140	108.6	15.7
160	124.2	17.9
180	139.8	20.1
200	155.2	22.4
225	174.6	25.5
250	194.2	27.9
280	217.4	31.3
315	244.6	35.2
355	275.6	39.7
400	310.6	44.7
450	349.4	50.3
500	388.4	55.8
560	435	62.5
630	489.4	70.3

O/D	I/D	S(mm)
20	14	3
25	18	3.5
32	23.2	4.4
40	29	5.5
50	36.2	6.9
63	45.8	8.6
75	54.4	10.3
90	65.4	12.3
110	79.8	15.1
125	90.8	17.1
140	101.6	19.2
160	116.2	21.9
180	130.8	24.6
200	145.2	27.4
225	163.4	30.8
250	181.6	34.2
280	203.4	38.3
315	228.8	43.1
355	258	48.5
400	290.6	54.7
450	327	61.5
500	363.4	68.3
